Turbosmart GenV WG40M CompGate40 Motorsport 14psi Black TS-0552-1102

Turbosmart GenV WG40M CompGate40 Motorsport 14psi Black TS-0552-1102

Regular price £431.87 GBP
Regular price Sale price £431.87 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

Product Description





GenV CompGate40M ‘Motorsport’ 14psi External Wastegate (Black)


TS-0552-1102


Based on the modular architecture of the GenV range, the Motorsport version has an extra CFD driven heatsink built in proven to dissipate more heat and further isolate the actuator housing from thermal stress.

The GenV provides extensive user configurability, world leading extended thermal performance, fatigue resistance and best in class flow performance for optimum control and longevity.

The GenV External Wastegate from Turbosmart was a ground up rework of a classic and the only feature that rolled over from the Gen4 range was the mounting orientation.

CFD optimized and validated in-house for maximum flow and thermal management, the GenV range has more features, options and performance than any other gate like it.

A direct fit upgrade to all Gen4 Turbosmart wastegates and feature our unique collar-locking system, variable actuator cap and base for easy, 360 degree optional routing of reference hoses, strap-type V-band clamps, optional liquid-cooling provision, 1/8″ NPT reference ports and are provided with the full range of available springs.


Supplied With

GenV Wastegate unit

All Springs Included in Box

Wastegate Pre-fitted as Per Description

GenV SS316 Valve seat

GenV V-Band Clamps

GenV Inlet & Outlet Flanges

Mounting Bolts and Nuts

Collar tool (master/slave)

4 x 1/8” NPT plugs (1x installed)

2 x 1/8” NPT nipples

Turbosmart Decal


Features

CFD Driven heatsink design

Class Leading, Thermal Performance

Class Leading, CFD & Bench Validated Flow Performance

Class Leading Fatigue Resistance

Nitronic 60 Valve Guide & High Temp 347 SS Body

17/7 PH Stainless Steel Springs

Liquid Actuator Cooling Option

Strap Type V-band clamps





View full details
